The LR-5100 Insulated Opening System offers superior thermal and acoustic performance with its advanced insulation technology. Designed for modern architectural needs, it combines durability, energy efficiency, and versatile opening options to create comfortable, high-performance spaces.
- Improved Thermal Insulation: Achieved through different profile combination possibilities.
- Inward and Outward Opening Compatibility: Supports applications for functional versatility.
- Durable Sealing and Hinge Mechanisms: Ensure long-lasting performance.
Sliding Types
The LR-5100 Insulated Opening System offers a wide range of configurations, supporting both window and door applications. Its versatile design allows for seamless integration into various architectural layouts, providing flexibility, enhanced functionality, and consistent thermal and acoustic performance across all opening types.
For more information about available configurations, please contact us.
Application Features
- Ease of Use and Functionality
- Adjustable Lock Strike
- Triple Glass with Blinds Glass Possibility
- Heat and Sound Insulation
- Fly Screen
- Low Threshold Option
- Double Opening
- Hidden Sash
Technical Specifications
- Sash Width 72 mm
- Sash Length (Min.) 90 mm
- Frame Width 72 mm
- Glass Thickness 16-42 mm
- Max. Sash Carrying Capacity 120-200 kg
- Insulation Bridge 24 mm
