Our system combines superior insulation and energy efficiency with smooth, effortless sliding performance. The 3100 series further enhances this performance with a sleek, modern profile designed for durability and minimal maintenance.
- Minimal Architectural Solution: Provides a clean, modern appearance with a 50% reduced center mullion for enhanced transparency.
- High-Security Locking: Equipped with a specially designed high-strength multi-point locking system for improved safety.
- Thermal Efficiency: Features a polyamide-profiled hollow center detail to support thermal insulation.
- Ease of Use: Designed for simplified production and installation, reducing labor time and complexity.
Sliding Types
34 mm middle sash profile at 90° sash joints allows more light to enter your home. Special flyscreen rail frame and useful flyscreen sash in 90° and 45° sash combinations.
For more information about available configurations, please contact us.
Application Features
- Water, Air Insulation Energy Savings Special Steel Rail Fly Screen Multi Lock Application Ease of Use and Functionality Minimal Middle Sash 45° and 90° Sash Joint 3 Track Frame Mono Rail Frame
Technical Specifications
- Sash Width 32 mm
- Sash Length 75 mm
- Frame Length 44mm
- Glass Thickness 30-32 mm
- Max. Sash Carrying Capacity 120 kg
- Insulation Bridge 21 mm
- The Middle Sash Width 34–78.5 mm
